5Kwh Wall Power LiFePO4 Battery 24V lithium ion Battery Solar Home Energy Storage System 24V Powerwall

ES- 5.12L 24V | 200AH | LiFePO4 Battery

Model	ES-5.12L
Total Energy [kWh]	5.12
Capacity [Ah]	200
Nominal Voltage [V]	25.6
Voltage Range [M]	24-28.8V
MAX.Charge & Discharge Current[A]	80
Dimension[W×DxH,mm]	220×270×550
Net Weight [Kg]	33.5KG

Introduction Specification ES-5.12L Detial System connect

Introduction

24V 200ah LiFePO4 Battery

95% DOD with More Usable Capacity

Long cycle life：More than 6000 Cycles

Compatible with most of available solar inverters

Support CAN&RS485 Communication

Equipped Smart BMS

Warranty：5 Years

Wall mounted lithium battery is mainly for home energy stoarge solutions

Model	ES-5.12L	ES-10.24L	ES-15.36L	ES-17.92L
Total Energy [kWh]	5.12	10.24	15.36	17.92
Capacity [Ah]	200	200	300	350
Nominal Voltage [V]	25.6	51.2	51.2	51.2
Voltage Range [V]	21-28.8	48-57.6	48-57.6	48-57.6
MAX. Charge & Discharge Current [A]	50	80	120	150
Peak Charge & Discharge Current [A] (for 10 sec.)	80	120	150	200
Dimension [W x D x H, mm]	220270550	610×160×800	577680280	721680280
Net Weight [Kg]	34	72	110	135
Scalable	1~16 in parallel
Communication	CAN,RS485
Communicated Inverter	GOODWE / Victron / SOFAR / Deye / Growatt / Solis / SMA / SRNE
Enclosure Protection Rating	IP21
Working Temperature Range [℃]	-10 ~ 50
Cycle Life	＞6,000 Cycle@ 80% DOD / 25℃ / 0.5C, 60%EOL
Warranty	5 years
Certification	IEC62619,UN38.3,CE
