MS-450 450W|Half-cut|MONO

مطلوب الان تحميل

Introduction Specification MS-450 Detail Company

Introduction

Mono Half-cut single/Double Glass Module

Saving logistics cost Saving cable cost

Saving bracket cost Saving labor cost

10-year warranty for material and technology

25-year linear power output warranty

Module Type	MS-450W
Maximum Power (Pmax/W)	450
Open Circuit Voltage(VocN)	41.25
Short Circuit Current(lsc/A)	13.89
Maximun Power Voltage(VmpN)	34.67
Maximum Power Current(lmp/A)	12.98
Module Efficiency(%)	20.80
Under Standard Test Conditions (STC) of irradiance of 1000 W/m2, spectrum AM 1.5 and cell temperature of 25°C.
ELECTRICAL PARAMETERS	AT NOCT
Maximum Power (Pmax/W)	340
Open Circuit Voltage(VocN)	38.65
Short Circuit Current(lsc/A)	11.08
Maximun Power Voltage(Vmp/V)	38.65
Maximum Power Current(lmp/A)	11.08
Output Tolerance	0~+5W
